EQUIPMENT:                 50V DC. combined battery/charger tripping supply unit.



UNIT REFERENCE:       TSU5070M-6.  (Previously SWT5070M-6)



HOUSING:                     Wall mounting, welded fabrication, steel enclosure with hinged door and un-drilled gland plates.

Dimensions:                   720mm high x 480mm wide x 150mm deep.

Finish:                            Grey to RAL7035.

Weight:                          34Kg.



BATTERIES:                  Sealed nickel cadmium type, having a long maintenance-free life.

Capacity:                       8.0Ah.

Number of cells:             40.

Max. peak discharge for 0.3sec to 0.65V/cell:       160A.



INPUT:                          220-250V AC.  50/60Hz.  Single phase.  Full load:            210VA.



OUTPUT:                       Nominal voltage:             50V DC.

Maximum voltage:          57.5V DC.

Minimum voltage:           42.0V DC.



Tripping (pulse) output.

Maximum current:           70A for 0.1sec.



Standing load (continuous) output.

Maximum current:           2.0A.

Available capacity:          3.0Ah.



ACCESSORIES:            Mains input MCB.

Mains pilot lamp.

Dummy load test pushbutton.

Battery/output voltmeter.



PROTECTION:               Mains input:                   Double pole, thermal MCB - 5A.

Charger output:              Single pole, fuse - 20mm 1A.

Rectifier input:                Single pole, fuse - 20mm 6.3A.

Tripping output:              None.

Standing load output:      Single pole, fuse - NIT 6.



TERMINALS:                 Mains input:                   WDU2.5.

Tripping output:              STL5.

Standing load output:      WDU6.

Alarms output:                WDU2.5.



ALARMS:                       Standard:                       Charge failed.                 )            Each with either;

Optional:                        Mains failed.                   )            2 x c/o contacts, or,

(May                              Low voltage.                   )            1 x c/o contact (or

  affect                           High voltage.                  )            o/p to com. alarm) +

  cubicle                         Earth fault.                     )            local pilot lamp.

  Size).                           Common alarm.              - with     2 x c/o contacts.
