SPARE BATTERY PACKS





SAFT BATTERY PACK DETAILS



DESCRIPTION

CODE

SAFT TYPE

WEIGHT

DIMENSIONS



NUMBER



(Kg)

L x W x H (mm)











2 CELL VR1.2

262 – 027

0764-502-B FORM

0.110

85 x 23 DIA

5 CELL VR1.2 *1

262 – 010A

0764-505-201

0.286

69.6 x 47.5 x 45.5

10 CELL VR1.2 *1

262 – 009A

0764-510-201

0.539

114 x 47.5 x 45.5

10 CELL VR2 *2

262 – 018

0765-510-201

0.803

130 x 53.8 x 53.1

5 CELL VR4 *3

262 – 001

0767-505-201

0.852

102.2 x 69.8 x 66.5

10 CELL VR4 *3

262 – 046

0767-510-201

1.617

167 x 69.8 x 66.5

2 CELL VR7 *4

262 – 026

0768-502-201

0.5

37.4 x 69.8 x 97.3

5 CELL VR7 *4

262 – 012

0768-505-201

1.32

102.2 x 69.8 x 97.3

6 CELL VR7 *4

262 – 028

0768-506-201

1.518

102.2 x 69.8 x 97.3

8 CELL VR7 *4

262 – 015

0768-508-201

2.024

134.6 x 69.8 x 97.3

10 CELL VR7 *4

262 – 045

0768-510-201

2.53

167 x 69.8 x 97.3

2 CELL VR10 *5

262 – 016

0769-502-201

0.83

46 x 87.8 x 95.2*6

4 CELL VR10 *5

262 – 004

0769-504-201

1.661

87.8 x 87.8 x 95.2*6

5 CELL VR10 *5

262 – 007

0769-505-201

2.145

129.2 x 87.8 x 95.2*6

6 CELL VR10 *5

262 – 050

0769-506-201

2.486

129.2 x 87.8 x 95.2*6

10 CELL VR10 *5

262 – 044

0769-510-201

4.147

212 x 87.8 x 95.2*6





Note *1 - Capacity now 1.5Ah.

Note *2 - Capacity now 2.3Ah.

Note *3 - Capacity now 4.5Ah.

Note *4 - Capacity now 8.0Ah.

Note *5 - Original Cell now obsolete, Ni-Mh alternative available capable of an equivalent duty.

Note *6 - Original Cell Dimensions.





Batteries other than those originally fitted in the equipment may not be capable of the switchgear loads that the unit is intended to supply which is why we offer guaranteed compatible replacements.





OTHER MANUFACTURERS BATTERY CELLS





We have very good trading relationships with all the major battery cell manufacturers, including; Alcad, Saft, Yuasa, Enersys (Hawker, Chloride) and Sonnenschein, and can supply replacement batteries for most installations at competitive prices.  We can offer direct or near equivalent cells for; vented nickel cadmium, sealed (valve regulated recombination) lead acid and vented lead acid (tubular plate, flat plate and Plante) types.  We can arrange to find an appropriately sized alternative to most obsolete cells that will fit within an existing enclosure.  We also offer a site service to strip out the old cells, fit new replacements and arrange recycling of the old battery.
